Molybdenum Plates
Product name:Molybdenum plate
Purity:>=99.95%
Density:≥10.2g/cm3
Finished:Annealed, shaped in hi-temperature, special heat treatment, mirror surface and other special requirements from customers.
99.95% Pure Molybdenum plates
have high temperature resistance, hardness and density. Our process starts with raw metal powder that is then pressed into ingots, sintered and hot rolled. The process enables us to tailor the product to meet specific customer material and performance requirements to ensure optimal performance in your application.We offers a wide range of hot rolled plate and cold rolled molybdenum sheet product in a range of thicknesses, widths, and lengths,and surface finish as outlined below.
Molybdenum plates
Material:99.95wt% molybdenum powder
Density:Mo≥9.3
Finished as:Annealed, shaped in hi-temperature, special heat treatment, mirror surface and other special requirements from customers.
Application:
-Parts of Electric Light Sources and Electron Tubes;
-Medical Facilities;
-Obstruction of Radiation and Interference;
-To Heat Elements of High Temperature Furnaces;
-Structures of High Temperature Furnaces.
Composition performance parameters of molybdenum products | |||
Type | The main content(%) | The density of(g/cm³) | hardness(HV10) |
MGPM | Mo≥99.95 | ≥10.15 | 130-180(Recrystallization annealing) 190-280(Stress free annealing) |
MGPMLa | Mo:≥99.3:; La2O3:(0.3-0.7) | ≥10.1 | 140-180(Recrystallization annealing) 190-280(Stress free annealing) |
MGPTZM | Mo≥99.3 C:(0.01-0.04) O:≤0.05 Ti:(0.4-0.55) Zr:(0.06-0.12) | ≥10.05 | 180-280 HRC(18-28) |
The thickness of the(mm) | The width of the(mm) | The length of the(mm ) | Roughness (Ra) |
1.0-3.0 | ≤300 | ≤800 | 0.4-0.8 |
>3.0-10.0 | ≤500 | ≤1000 | |
>10.0 | ≤300 | ≤1000 |
Features: sandblasting surface molybdenum plate
1. MoLa molybdenum alloy plate is processed to obtain maximum ductility for applications;
2. The purity of molybdenum powder material is 99.95%; high temperature MoLa molybdenum plate
3. The amount of lanthanum for mixing is precisely controlled and well blended;
4. The density of Mo-la plate is more than 10g/cm3;
5. Mo-la plate is under vacuum annealing and leveling before delivery;
6. Our MoLa molybdenum alloy plate is approved by ASTM B386.
