Product Name: Gr4 titanium bar
Standard: ASTM B348
Material: Grade 4
Unit Price: $15usd/kg- $45usd/kg
Shape: Round
Diameter: 6-350mm
Length: Max 6000mm
Surface: Bright
Condition: Annealed

Send Inquiry

Chat Now

Product Introduction

Gr4 titanium bar

Standard: ASTM B348

Material: Grade 4 titanium

Unit Price: $15usd/kg- $45usd/kg

Shape: Round

Diameter: 6-350mm

Length: Max 6000mm

Surface: Bright

Condition: Annealed

Grade 4 titanium bar
Chemical compositions(weight%,<=)
Ti	Al	V	Fe	C
Remainder	-------	-------	0.50	0.08
N	H	O	Other(each)	Other(total)
0.05	0.015	0.40	0.10	0.40
Physical properties(>=)
Σb Tensile Strength (Mpa)	σr0.2 Yield Strength (Mpa)	δL0+50mm Elongation (%)	ψ Reduction of area (%)
580	485	15	25

Titanium Round Bar Dimensions

Φ 2	Φ 3	Φ 3.5	Φ 4	Φ 5
Φ 6	Φ 7	Φ 8	Φ 9	Φ 10
Φ 12	Φ 13	Φ 14	Φ 15	Φ 16
Φ 18	Φ 20	Φ 22	Φ 25	Φ 26
Φ 30	Φ 32	Φ 35	Φ 40	Φ 45
Φ 50	Φ 55	Φ 60	Φ 65	Φ 70
Φ 75	Φ 80	Φ 85	Φ 90	Φ 95
Φ 100	Φ 105	Φ 110	Φ 120	Φ 130
Φ 140	Φ 150	Φ 160	Φ 170	Φ 180
Φ 190	Φ 200	Φ 210	Φ 220	Φ 230
Φ 240	Φ 250	Φ 260	Φ 270	Φ 280
Φ 290	Φ 300	More Dimensions	Please	Contact us
