Titanium Sheet Grade 5
Product name:Titanium sheet grade 5
Grades: Gr5
Standard: ASTM B265 ,AMS 4911, ASTM F136
Thickness: 1.0mm, 3.0mm, 6.0mm, 10mm, 12mm, 15mm 16mm,
20mm,25mm,30mm,35mm etc.
Width:200-3000mm
Length:500-6000mm
Supply status: Annealed(M)
Package: Carton box or plywood case.
MTC: EN10204.3.1 certificate
MOQ : 10 kgs
Applications : Petroleum ,chemical industry, Marine etc.
Send Inquiry
Chat Now
Product Introduction
Product name:Titanium sheet grade 5
Grades: Gr5
Standard: ASTM B265 ,AMS 4911, ASTM F136
Thickness: 1.0mm, 3.0mm, 6.0mm, 10mm, 12mm, 15mm 16mm, 20mm,25mm,30mm,35mm etc.
Width:200-3000mm
Length:500-6000mm
Supply status: Annealed(M)
Package: Carton box or plywood case.
MTC: EN10204.3.1 certificate
MOQ : 10 kgs
Applications : Petroleum ,chemical industry, Marine etc.
Titanium sheet / Titanium Plates Manufactured according to ASTM B265 ,AMS 4911, ASTM F136 ,ASTM F67.
Customized cuttings on demand.
| Materials | Manufacturing Process | Processing State | Standards |
| Gr1, 2, 3, 7, 11, 12, 17 | Hot rolled (3.0mm < thickness < 60mm) | Hot rolled, annealed Shot blasting Acid picking | ASTM B265 AMS 4911,ASTM F136,ASTM F67 |
| Gr1, 2, 3, 7, 11, 12, 17 | Cold rolled (0.2mm < thickness < 4.0mm) | Cold rolled, annealed smooth | ASTM B265 AMS 4911,ASTM F136,ASTM F67 |
| Hot rolled (4.1mm < thickness < 60mm) | Hot rolled, annealed Shot blasting Acid picking | ASTM B265 AMS 4911,ASTM F136,ASTM F67 | |
| Gr1, 2, 3, 7, 11, 12, 17 | Cold rolled (0.2mm < thickness < 4.0mm) | Cold rolled, annealed smooth | ASTM B265 AMS 4911,ASTM F136,ASTM F67 |
| Dimensions (T*W*L) [mm] Actual dimensions depend on the material used. | (0.3-0.5) x ≤600 x ≤1500 (0.6-0.8) x ≤800 x ≤1200 (0.9-6.0) x ≤1000 x ≤3000 (5.0-8.0) x ≤2500 x ≤4000 (8.0-60) x ≤2800 x ≤12000 | ||
