Titanium Coil Wire 1mm 2mm Price Per kg For Braces Welding

Product Name: Titanium Weld Wire
Standard: AWS A5.16
Material: Gr1, Gr2 ,Gr3, Gr4,Gr5, Gr7,Gr12
Unit Price: $21.5usd/kg-$60usd/kg
Shape: Straight, Spool, Coil
Diameter: 0.8mm/1mm/1.2mm/1.6mm/2mm/2.4mm/3mm/3.2mm etc.
Surface: Pickling,polishing
MOQ:10kgs
Factory Area:3000 ㎡
Company staff:48
Foreign trade team service staff:20
China's professional titanium wire manufacturer
Send Inquiry
Chat Now
Product Introduction

Titanium coil wire 1mm 2mm price per kg for braces welding

Brands: ERTI-1, ERTI-2, ERTi-3, ERTI-4, ERTi-5
Implementation standards: AWS A5.16, GB/T3623, ASTM B865
Specifications:¢1.0, 1.2, 1.6mm (Titanium Welding Wire On Spool)
Surface treatment: bright surface
Surface quality: high precision, good finish, no oxidation color, no cracks, peeling, pricking, speckles and inclusions. Minor local
scratches, scrapes, spots, pits, etc., not exceeding the allowable deviation of the wire diameter are allowed.



Titanium Welding Wire On Spool is applied in aerospace, aviation, military industry, light industry, chemical industry, 3D printing, welding, textile, electronics, superconductivity, medical and petrochemical fields. It is available with a variety of specifications and types, and we can also have stocks as customer requires. This wire also has a metallic luster and is malleable. Its main characteristics are low density, high mechanical strength and easy processing, meanwhile, it has good corrosion resistance and is not affected by the atmosphere and seawater.







ASTM Base Metal GradeBase metalNormal compositionRecommended Filler Metal
 UTS(min.) ksi[Mpa]YS(min.) ksi[Mpa]
Grade 135[240]20[138]Unalloyed Ti CP1ERTi-1
Grade 250[345]40[275]Unalloyed Ti CP2ERTi-2
Grade 480[550]70[483]Unalloyed Ti CP4ERTi-4
Grade 5130[895]120[828]Ti 6AL-4VERTi-5
Grade 750[345]40[275]Ti 0.15PdERTi-7



AWSCHEMICAL SPECIFICATIONS
AWS A5.16UNSCONHIAlVPd
 Number
ERTi 1R501000.030.03-0.100.0120.0050.08---
ERTi 2R501200.030.08-0.160.0150.0080.12---
ERTi 4R501300.030.08-0.320.0250.0080.25---
ERTi 5R564000.050.12-0.200.030.0150.225.5-6.73.5-4.5-
ERTi 7R524010.030.08-0.160.0150.0080.12--0.12-0.25
