Titanium Shell Tube Heat Exchanger

Our Titanium shell tube heat exchanger consists entirely of a titanium shell and internal titanium tubes, ensuring adequate turbulence and avoiding inefficient laminar flow. Our Titanium shell tube heat exchangers have a wide range of cooling and heating capacities from 1 to 20 tons for cooling and 4 to 375 tons for heating! These units can be used with boilers for heating or cooling with glycol coolers or geothermal systems. These units offer the best combination of affordability, reliability and efficiency in the industry today.

These Titanium shell tube heat exchanger can be installed in a variety of ways to provide optimal heating and/or cooling for many applications. There are few wrong answers when it comes to installation, but achieving optimal heat exchange performance with minimal additional hardware and minimal energy consumption may require some tinkering and testing.

Features:

Consists entirely of titanium: housing and port assemblies, internal titanium tubing and TIG welded titanium packing.

Titanium tubes enhance heat exchange by adding turbulence inside and outside the tube and reducing laminar flow at higher pressures/flows.

Ample port sizes for tube and shell ports provide a wide flow range.

The unit is fully welded, reducing the possibility of maintenance and leakage.

All-titanium construction means maximum protection against corrosion, pitting and wear, without regard to weaknesses.

Product name:Titanium shell tube heat exchanger, titanium tube heat exchanger, titanium heat exchanger

Shell material:SS304/SS316/Titanium

Tube material:Grade 2 Titanium

Tube plate material:Titanium steel composite

Dimension:customized

Structure:Tube Heat Exchanger

Liquid Flow Rate:customized

Maximum Working Pressure:customized

Voltage:customized

Usage:pharmaceutical, chemical factory etc.

After-sales Service:

Video technical support

Field installation

commissioning and traning

field maintemance and repair service

online support etc.

Life cycle benefits of titanium heat exchangers

Titanium heat exchangers are cost-effective throughout the life cycle of equipment. If properly maintained, titanium heat exchangers can operate for decades, making them a very economical option.

Why choose titanium heat exchanger?

Titanium is one of several metals that belong to the category of active metals or corrosion resistant alloys (CRA). For this particular group of materials, reduction or oxidation environments at temperatures up to 1200°F are possible, with or without chloride. In addition to its high resistance to uniform corrosion, CRA is very successful at resisting pitting, cracking and stress corrosion.

Titanium is used as a structural material for heat exchangers in chemical, petrochemical, oil and gas and other industrial manufacturing environments. During these processes, corrosive liquids (usually at very high temperatures and/or pressures) come into contact with the surface of the equipment to test the strength and corrosion resistance of the material.

Detailed images:

The working principle of air radiator is to use efficient finned tube as heat transfer element, steam, air and other fluids become medium, and then through the intensified heat transfer of finned tube, in order to achieve the purpose of heating and cooling the working medium in the tube or heating and cooling the air with the working medium in the tube. Air radiator is suitable for liquid and gas heat exchange equipment, air heater is widely used in hot air heating, air conditioning, cooling, dehumidification, drying and other industrial and civil fields.
